The Purplelec PEC-TX007 is a truly unique device. It boasts more ports than any other Thunderbolt docking station, yet its form factor remains the same as the previous-generation Thunderbolt 4 Hub, making it incredibly compact. With its rich and powerful port selection, it's the perfect way to expand your workflow while minimizing desk space.
Despite its small size, this device packs many features typically found in high-end docking stations. For instance, it offers 90W continuous host charging, connection speeds of up to 120Gb/s, and support for up to three monitors on Windows Thunderbolt 5 PCs that support this configuration. Connect to the content you need anytime, anywhere.
The PEC-TX007 Thunderbolt 5 hub is compatible with Thunderbolt 5, Thunderbolt 4, Thunderbolt 3, USB4, USB4 v2, and USB-C devices. Additionally, it is compatible with iPads, iPhones, Windows tablets, and other devices* equipped with USB-C or Thunderbolt interfaces.
The PEC-TX007 is equipped with four Thunderbolt 5 ports and one USB-A (10 Gb/s) port. It is compact and portable yet provides powerful connectivity. The included power supply is 42% smaller than that of the previous-generation product, making it even more convenient to carry.
On macOS, the PEC-TX007 can connect up to two 6K or 8K 60Hz extended displays to a Mac and supports dual displays via a single Thunderbolt connection. (M4 Thunderbolt 5 Macs do not support triple-display setups via a single Thunderbolt 5 connection.)
On Windows Thunderbolt 5 PCs, the PEC-TX007 can support up to three external extended displays, provided the PC supports this configuration. Windows Thunderbolt 4 PCs can connect up to two extended displays, but this also requires support from the computer.
In terms of power supply, the PEC-TX007 supports up to 90W of power for charging devices. Thanks to its 180W power adapter, unlike other hubs, it can continuously provide up to 90W of power. The downstream Thunderbolt 5 ports can provide up to 15W of power, while the USB ports can provide up to 7.5W of power. The offline charging feature of the PEC-TX007 allows users to charge all devices even when the hub is not connected to the host.
Interface
1x Thunderbolt 5 Host (Up to 120Gb/s)
3x Thunderbolt 5 (80Gb/s)
1x USB-A (10Gb/s)
1x DC In (20V | 7.5A)
Minimum System Requirements
macOS 15 or above
Windows 11 or above
iPadOS
Chrome OS
Thunderbolt 5 Computer
Thunderbolt 4 Computer
Thunderbolt 3 Mac
USB-C (USB4 or USB4 v2) Computer
USB-C Computer/Tablet/Phone
Thunderbolt/USB4 iPad
USB-C ChromeBook
